TRACOM Wet Well Manholes

Home>Process>Fiberglass>TRACOM Wet Well Manholes
◄
TRACOM Wet Well Manholes

A messy necessity in wastewater and sanitation, wet wells provide an easily accessible base for any lift station. Wet Well Manholes provide an easy-to-install, drop-in-place flow metering solution. Tracom’s fiberglass superstructure is lightweight and quick to bring into service.

Features

Wet Well Manhole Design

Our fiberglass Wet Well Manholes are made from Polyester Resin with Polyester Gel Coating, giving excellent corrosion resistance as a minimum. Wet Well Manholes can be customized to use the right material for your application, including VinylEster Resin or a Resin-rich veil in lieu of gel coating.

Standard design calls for flanged and/or sleeved pipe connections outside. Tracom only uses the highest quality flanges, typically made from Hetron 922 Resin. Tracom flanges are 3rd party rated to conform to PS 15-69 & ASTM D5421. Inlets and outlets are completely customizable from height and center offset to pipe size. Whether you need a flanged connection or a pipe stub, anything is possible to get you what you need.

Wet Well Manhole Installation

When you purchase a wet well manhole from Tracom, you’re purchasing a water-tight product straight from the factory. Installation is quick, leaving penetration work to our team. Tracom personalizes your flanges and stubs for extreme ease of installation. Prevent expensive mistakes originating from field-assembled wet wells, and use a Tracom Wet Well Manhole for your application.

Wet Well Manholes arrive ready to set-in-place, with “ANSI 150lbs pattern” flanges or PVC pipe stubs with flexible sleeves outside for pipe attachment, as well as a polystyrene pad to place under the manhole when mounting. Inside is an OSHA compliant ladder and 2” NPT coupling penetration for wiring runs.

Specifications

Additional information

Fiberglass
